Quick Details

  • Quality Management System: ISO 9001
  • Certificate: CE
  • Duty: Continuous S1
  • Usage: Industrial
  • Protect Feature: Waterproof
  • Structure: Synchronous Motor
  • Phase: Three Phase
  • Speed: Variable Speed
  • Shape: Tubular
  • Power: AC

Packaging & Delivery

Packaging Details wooden boxes.
Delivery Time 30~60 days

YZR.YZ Series DC MOTOR

crane and metallurgical uses,
with brush,
IP 21S,
CE certificate.



There are eight types of duty type for these series motors, S2,S3,S4,S5,S6,S7,S8 and S9. The basic duty type is S340 (duty type is S3, cyclic duration factor is 40%, each cyclic is 10min). The following duty type are most useful to these series motors.


1.Short-time duty type (S2)
     Operation of constant load during a given time, less than that required to reach thermal equilibrium, followed by a rest and de-energized period of sufficient duration to re-establish machine temperature within 2 deg K of the coolant.


2. Intermittent periodic duty type (S3)
    A sequence of identical duty cycles, each including a period of operation at constant load and a rest and de-energized period but the operation period are so short that it is not sufficient for the machine to reach thermal equilibrium In this duty type, the cycle is such that the starting current does not significantly affect the temperature rise.


3. Intermittent periodic duty type with starting (S4)
    A sequence of identical duty cycles, each including a significant period of starting, a period of operation of constant load and a rest and de-energized period, but the operation period are so short that it is not sufficient for the machine to reach thermal  equilibrium.


4. Intermittent periodic duty type with electric braking (S5)
    A sequence of identical duty cycles, each consisting of a period of starting, a period of operation at constant load and a rest and de-energized period, but the operation period are so short that it is not sufficient for the machine to reach thermal equilibrium.


5. The motor will operate satisfactorily under following conditions:
    (1) Ambient temperature not exceeding 40 (for crane uses) or 60 (for metallurgical uses).
    (2) Not above sea-level 1000m.
    (3) Frequent and significant mechanical vibration and shocks.
    (4) Frequent starting, braking(electrical or mechanical) or reversing.


6. The rated frequency of the motor is 50Hz and rated voltage is 380V.


7. Connection: The stator winding is connected in Y for 132kW and below and in for the rest. In Y with zero lead is also supplied.



8. Output and speed
    The range of rated output and, as-ynchrouons speed for the basic duty type (S3-40%) are shown in our website.
